Brands |
N/A Pyromation® |
Configuration Code |
N/A XP04 |
Agency Approval |
N/A Code HL06 - ATEX/IECEx Flame-Proof Certified Assembly |
Thermocouple Types |
N/A
Code E - Single Code J - Single Code K - Single Code T - Single Code EE - Duplex Code JJ - Duplex Code KK - Duplex Code TT - Duplex Code JJJ - Triplex Code KKK - Triplex |
Sheath Diameter (316 Stainless Steel) |
N/A Code 48 - 1/4 in. |
Measuring Junctions |
N/A Code U - Ungrounded |
Thermowell Selection |
N/A Select Thermowell from Thermowell Section. |
Element Options |
N/A
Code FP - Spring-Loaded Element with Flame Path (Only available with 8HN and 8XU Head Mounting Fittings) Code FE - Fixed Element |
Head Mounting Steel Fittings |
N/A
Code 6HN - 1/2 in. x 1/2 in. NPT Hex Nipple Code 6PN - 1/2 in. NPT Pipe Nipple (Specify "E" Length in inches) Code 6XU_(3-1/2 in Minimum Length required. Maximum "E" Length is 9") - 1/2 in. NPT Union/Nipple (Specify "E" Length in inches) |
Head Mounting 316 Stainless Steel Fittings |
N/A
Code 8HN - 1/2 in. x 1/2 in. NPT Hex Nipple Code 8PN - 1/2 in. NPT Pipe Nipple (Specify "E" Length in inches) Code 8XU_(3-1/2 in. Minimum Length required. Maximum "E" Length is 9") - 1/2 in. NPT Union/Nipple (Specify "E" Length in inches) |
Head Terminations |
N/A
Code 75T142E - 4 to 20 mA HART® Field Transmitter with Aluminum Flame-Proof Housing Code 77T-662E - 4 to 20 mA HART® Field Transmitter with Dual Cavity Aluminum Flame-Proof Housing Code 93 - Aluminum Flame-Proof Head Code 94 - 316L Stainless Steel Flame-Proof Head |
Options |
N/A
Code SB - 1/2 in. NPT Conduit Reducer Bushing, Aluminum Code I - Stainless Steel Tag Code M2 - M20x1.5 Conduit Reducer Bushing, Nickel Plated Brass Code M5 - M25x1.5 Conduit Reducer Bushing, Nickel Plated Brass Code T71 - 4 to 20 mA Isolated Head-Mounted Transmitter Code T72 - 4 to 20 mA HART® Isolated Head-Mounted Transmitter Code T82-00 - 4 to 20 mA Dual Input, Isolated HART® Head-Mounted Transmitter |
